用于中小体积生物样本存储，40-170升，气相、液相可选，液氮消耗量低，2ml冻存管存储容量为750-6000份，通过温度和液位的监控和报警，远程实时监控与报警，数据记录，自动灌注和过溢保护，自动排气等功能保证样本的安全性。
优点
附件选择
任一类型的冻存管(2ml或 5ml), 都有相匹配的架体附件(ARPEGE 70/110/140/170)。
独特的盒锁系统有效的避免了样品掉落的危险
新型适配于麦管的附件，使您可以及时存取样品，优化存储结构。
存储监控
全方位电子监测和控制系统可供选择: ARPEGE液氮罐在各项数据和附件设计上都可以说是优秀的液氮罐。样本的储存可通过Coolbase数据库程序在电脑上进行管理。
安全
新型除气装置防止气体在自动灌注过程中进入液氮罐
ARPEGE系列液氮罐
|
参数
|
ARPEGE40
|
ARPEGE70
|
ARPEGE110
|
ARPEGE140
|
ARPEGE170
|
ARPEGE55
|
ARPEGE75
|
|
尺寸
|
|
有效容积 (L)
|
40
|
72
|
116
|
144
|
172
|
55
|
72
|
|
口径(mm)
|
120
|
215
|
215
|
215
|
215
|
378
|
378
|
|
带附件的空罐重(kg)
|
25
|
33
|
42
|
50
|
56
|
31
|
37
|
|
满罐重(kg)
|
57
|
91
|
136
|
166
|
195
|
75
|
95
|
|
外径 (mm)
|
467
|
586
|
586
|
683
|
683
|
468
|
468
|
|
总高(mm)
|
735
|
738
|
962
|
911
|
1028
|
755
|
930
|
|
消耗量
|
|
日蒸发量(L/天)*
|
0.29
|
0.6
|
0.65
|
0.65
|
0.7
|
2.4
|
2.5
|
|
静态保存时间(天)*
|
140
|
130
|
193
|
222
|
246
|
23
|
29
|
|
动态保存时间(天)***
|
88
|
82
|
121
|
139
|
154
|
14
|
18
|
|
2ml冻存管的储存容量
|
|
架子数
|
6
|
4
|
4
|
6
|
6
|
6***
|
6***
|
|
层数 (2ml冻存管)
|
5
|
5
|
9
|
8
|
10
|
9
|
12
|
|
盒子尺寸(mm)
|
76×76
|
133×133 三角抽屉
|
|
2ml冻存管总容量
|
750
|
2000 (100/盒)
|
3600
(100/盒)
|
4800
(100/盒)
|
6000
(100/盒)
|
3618
|
4824
|
|
5ML冻存管的储存容量
|
|
架子数
|
－
|
4
|
4
|
6
|
6
|
21提桶
|
21提桶
|
|
层数 (5ml冻存管)
|
－
|
3
|
5
|
4
|
5
|
1
|
2
|
|
5ml冻存管总容量
|
－
|
972
|
1620
|
1944
|
2430
|
1071(on holding canes)
|
2142(on holding canes)
|
|
麦管的储存容量
|
|
架子数
|
－
|
4
|
4
|
6
|
6
|
21提桶
|
21提桶
|
|
层数
|
－
|
2
|
3
|
3
|
4
|
3
|
4
|
|
0.25ml麦管总容量
|
－
|
19040
|
28560
|
42840
|
57120
|
51660
|
68880
|
|
0.5ml麦管总容量
|
－
|
6800
|
10200
|
15300
|
20400
|
22995
|
30600
|
|
CBS 0.5ml总容量
|
－
|
4760
|
7140
|
10710
|
14280
|
14175
|
18900
|
|
血包总容量
|
|
DF700总容量
|
－
|
－
|
－
|
－
|
－
|
24
|
48
|
|
其它包
|
－
|
－
|
－
|
－
|
－
|
联系我们
|
*日蒸发量和静态保存时间测试条件：20C，1013mb，液氮罐盖子关闭，无附件。
**动态保存时间为一般使用条件下的相对数据。
***当选择有电子附件时，架子数为5。
CE：ARPEGE系列液氮罐已经获得CE认证。
液氮罐监控管理
|
规格
|
编号
|
2ml冻存管
标准架附件
|
温度指示
|
液面指示
|
自动填充
|
远程控制
4/20mA
|
远程控制
RS485
|
除气装置
|
|
ARPEGE40
|
NH98100
|
●
|
|
|
|
|
|
|
|
NH101930
|
●
|
●
|
|
|
|
|
|
|
NH101931
|
●
|
|
●
|
|
|
|
|
|
NH101932
|
●
|
●
|
●
|
|
|
|
|
|
ARPEGE70
|
NH97711
|
●
|
|
|
|
|
|
|
|
NH101940
|
●
|
●
|
|
|
|
|
|
|
NH101941
|
●
|
|
●
|
|
|
|
|
|
NH101942
|
●
|
●
|
●
|
|
|
|
|
|
NH101943
|
●
|
|
●
|
●
|
|
|
|
|
NH101944
|
●
|
●
|
●
|
●
|
|
|
|
|
NH101945
|
●
|
●
|
●
|
●
|
●
|
|
|
|
NH101946
|
●
|
●
|
●
|
●
|
|
●
|
|
|
ARPEGE110
|
NH98023
|
●
|
|
|
|
|
|
|
|
NH101950
|
●
|
●
|
|
|
|
|
|
|
NH101951
|
●
|
|
●
|
|
|
|
|
|
NH101952
|
●
|
●
|
●
|
|
|
|
|
|
NH101953
|
●
|
|
●
|
●
|
|
|
|
|
NH101954
|
●
|
●
|
●
|
●
|
|
|
|
|
NH101955
|
●
|
●
|
●
|
●
|
●
|
|
|
|
NH101956
|
●
|
●
|
●
|
●
|
|
●
|
|
|
ARPEGE140
|
NH98400
|
●
|
|
|
|
|
|
|
|
NH101960
|
●
|
●
|
|
|
|
|
|
|
NH101961
|
●
|
|
●
|
|
|
|
|
|
NH101962
|
●
|
●
|
●
|
|
|
|
|
|
NH101963
|
●
|
|
●
|
●
|
|
|
|
|
NH101964
|
●
|
●
|
●
|
●
|
|
|
|
|
NH101965
|
●
|
●
|
●
|
●
|
●
|
|
|
|
NH101966
|
●
|
●
|
●
|
●
|
|
●
|
|
|
ARPEGE170
|
NH98046
|
●
|
|
|
|
|
|
|
|
NH101970
|
●
|
●
|
|
|
|
|
|
|
NH101971
|
●
|
|
●
|
|
|
|
|
|
NH101972
|
●
|
●
|
●
|
|
|
|
|
|
NH101973
|
●
|
|
●
|
●
|
|
|
|
|
NH101974
|
●
|
●
|
●
|
●
|
|
|
|
|
NH101975
|
●
|
●
|
●
|
●
|
●
|
|
|
|
NH101976
|
●
|
●
|
●
|
●
|
|
●
|
|
|
ARPEGE55
|
NH98519
|
●
|
|
|
|
|
|
|
|
NH101980
|
●
|
|
●
|
|
|
|
|
|
NH010981
|
●
|
●
|
●
|
|
|
|
|
|
NH101982
|
●
|
|
●
|
●
|
|
|
NH98856
|
|
NH101983
|
●
|
●
|
●
|
●
|
|
|
NH98856
|
|
ARPEGE75
|
NH98520
|
●
|
|
|
|
|
|
|
|
NH101990
|
●
|
|
●
|
|
|
|
|
|
NH101991
|
●
|
●
|
●
|
|
|
|
|
|
NH101992
|
●
|
|
●
|
●
|
|
|
NH98856
|
|
NH101993
|
●
|
●
|
●
|
●
|
|
|
NH98856
|
标准附件
|
ARPEGE 40
|
|
|
一套6个5层垂直支架 适配于1.2/2 ml冻存管
|
REF: NH97787-1
|
|
5层垂直支架适配于1.2/2 ml冻存管
|
REF: NH100226
|
|
ARPEGE 70
|
|
|
一套4个垂直支架 适配于1.2/2 ml冻存管
|
REF: NH97833-1
|
|
5层垂直支架 适配于1.2/2 ml冻存管
|
REF: NH100227
|
|
ARPEGE 110
|
|
|
一套4个9层的垂直支架 适配于1.2/2 ml冻存管
|
REF: NH97833-3
|
|
9层垂直支架 适配于1.2/2 ml冻存管
|
REF: NH100229
|
|
ARPEGE 140
|
|
|
一套6个垂直支架 适配于1.2/2 ml冻存管
|
REF: NH97833-4
|
|
8层垂直支架 适配于1.2/2 ml冻存管
|
REF: NH100231
|
|
ARPEGE 170
|
|
|
一套6个垂直支架 适配于1.2/2 ml冻存管
|
REF: NH97833-5
|
|
10层垂直支架 适配于1.2/2 ml冻存管
|
REF: NH100233
|
|
ARPEGE 55
|
|
|
一套6个垂直支架 适配于1.2/2 ml冻存管
|
REF: NH99121
|
|
带抽屉的支架 适配于1.2/2 ml冻存管
|
REF: NH99121-X
|
|
ARPEGE 75
|
|
|
一套6个垂直支架 适配于1.2/2 ml冻存管
|
REF: NH99122
|
|
12个抽屉的垂直支架 适配于1.2/2 ml冻存管
|
REF: NH99122-X
|
|
|
ARPEGE系列气相液氮罐
有四种规格的液氮罐可用于在气相下存储样品
|
优势：
· 将液相下交叉感染的风险最小化
· 保证使用者的安全。从罐中取出冻存架时无液氮滴落
· 型号齐全：有4种不同容积的液氮罐，从1600个到5400个2ml冻存管的冻存（ARP70－110－140－170）
· 具备标准的装备，可从ARPEGE液相转变为气相
· 没有液氮的阻力，取拿冻存架时更为方便省力
|
|
技术亮点：
· 全新的电子装备
· 全新的冻存架的设计
· 冻存夹：帮助您固定冻存盒
|
|
|
规格
|
ARPEGE 70
|
ARPEGE 110
|
ARPEGE 140
|
ARPEGE 170
|
|
2ml冻存管的储存容量
|
|
2ml冻存管总容量（100个/盒）
|
1600
|
3200
|
4200
|
5400
|
|
架子数
|
4
|
4
|
6
|
6
|
|
层数（2ml冻存管）
|
4
|
8
|
7
|
9
|
|
5ml冻存管的储存容量
|
|
5ml冻存管总容量
|
648
|
1296
|
1458
|
1944
|
|
架子数
|
4
|
4
|
6
|
6
|
|
层数（5ml冻存管）
|
2
|
4
|
3
|
4
|
|
麦管的储存容量
|
|
0.25ml总容量
|
9520
|
19040
|
28560
|
57120
|
|
0.5ml总容量
|
3400
|
6800
|
10200
|
15300
|
|
CBS0.5ml总容量
|
2380
|
4760
|
7140
|
10710
|
|
架子数
|
4
|
4
|
6
|
6
|
|
层数
|
1
|
2
|
2
|
3
|
|
重要参数
|
|
|
|
|
|
有效容积（l）
|
15
|
15
|
20
|
20
|
|
静态保存时间（天）
|
25
|
23
|
30
|
28
|
|
技术参数
|
|
|
|
|
|
口径（mm）
|
215
|
215
|
215
|
215
|
|
日蒸发量（l/day）
|
0.6
|
0.65
|
0.65
|
0.7
|
|
满灌重（kg）
|
50
|
60
|
73
|
77
|
|
外直径（mm）
|
586
|
586
|
683
|
683
|
|
总高（mm）
|
738
|
962
|
911
|
1028
|
液氮罐监控
|
|
2ml冻存管架
|
5ml冻存管架
|
麦管架
|
液面指示自动填充
|
温度指示
|
低温监控
|
远程控制4－20mA’’
|
远程控制RS485’’
|
|
ARPEGE70-G-103
|
●
|
|
|
●
|
|
|
|
|
|
ARPEGE70-G-104
|
●
|
|
|
●
|
●
|
|
|
|
|
ARPEGE70-G-106
|
●
|
|
|
●
|
●
|
●
|
|
|
|
ARPEGE70-G-107
|
●
|
|
|
●
|
●
|
|
●
|
|
|
ARPEGE70-G-108
|
●
|
|
|
●
|
●
|
|
|
●
|
|
ARPEGE70-G-203
|
|
●
|
|
●
|
|
|
|
|
|
ARPEGE70-G-204
|
|
●
|
|
●
|
●
|
|
|
|
|
ARPEGE70-G-206
|
|
●
|
|
●
|
●
|
●
|
|
|
|
ARPEGE70-G-207
|
|
●
|
|
●
|
●
|
|
●
|
|
|
ARPEGE70-G-208
|
|
●
|
|
●
|
●
|
|
|
●
|
|
ARPEGE70-G-303
|
|
|
●
|
●
|
|
|
|
|
|
ARPEGE70-G-304
|
|
|
●
|
●
|
●
|
|
|
|
|
ARPEGE70-G-306
|
|
|
●
|
●
|
●
|
●
|
|
|
|
ARPEGE70-G-307
|
|
|
●
|
●
|
●
|
|
●
|
|
|
ARPEGE70-G-308
|
|
|
●
|
●
|
●
|
|
|
●
|
|
ARPEGE110-G-103
|
●
|
|
|
●
|
|
|
|
|
|
ARPEGE110-G-104
|
●
|
|
|
●
|
●
|
|
|
|
|
ARPEGE110-G-106
|
●
|
|
|
●
|
●
|
●
|
|
|
|
ARPEGE110-G-107
|
●
|
|
|
●
|
●
|
|
●
|
|
|
ARPEGE110-G-108
|
●
|
|
|
●
|
●
|
|
|
●
|
|
ARPEGE110-G-203
|
|
●
|
|
●
|
|
|
|
|
|
ARPEGE110-G-204
|
|
●
|
|
●
|
●
|
|
|
|
|
ARPEGE110-G-206
|
|
●
|
|
●
|
●
|
●
|
|
|
|
ARPEGE110-G-207
|
|
●
|
|
●
|
●
|
|
●
|
|
|
ARPEGE110-G-208
|
|
●
|
|
●
|
●
|
|
|
●
|
|
ARPEGE110-G-303
|
|
|
●
|
●
|
|
|
|
|
|
ARPEGE110-G-304
|
|
|
●
|
●
|
●
|
|
|
|
|
ARPEGE110-G-306
|
|
|
●
|
●
|
●
|
●
|
|
|
|
ARPEGE110-G-307
|
|
|
●
|
●
|
●
|
|
●
|
|
|
ARPEGE110-G-308
|
|
|
●
|
●
|
●
|
|
|
●
|
|
ARPEGE140-G-103
|
●
|
|
|
●
|
|
|
|
|
|
ARPEGE140-G-104
|
●
|
|
|
●
|
●
|
|
|
|
|
ARPEGE140-G-106
|
●
|
|
|
●
|
●
|
●
|
|
|
|
ARPEGE140-G-107
|
●
|
|
|
●
|
●
|
|
●
|
|
|
ARPEGE140-G-108
|
●
|
|
|
●
|
●
|
|
|
●
|
|
ARPEGE140-G-203
|
|
●
|
|
●
|
|
|
|
|
|
ARPEGE140-G-204
|
|
●
|
|
●
|
●
|
|
|
|
|
ARPEGE140-G-206
|
|
●
|
|
●
|
●
|
●
|
|
|
|
ARPEGE140-G-207
|
|
●
|
|
●
|
●
|
|
●
|
|
|
ARPEGE140-G-208
|
|
●
|
|
●
|
●
|
|
|
●
|
|
ARPEGE140-G-303
|
|
|
●
|
●
|
|
|
|
|
|
ARPEGE140-G-304
|
|
|
●
|
●
|
●
|
|
|
|
|
ARPEGE140-G-306
|
|
|
●
|
●
|
●
|
●
|
|
|
|
ARPEGE140-G-307
|
|
|
●
|
●
|
●
|
|
●
|
|
|
ARPEGE140-G-308
|
|
|
●
|
●
|
●
|
|
|
●
|
|
ARPEGE170-G-103
|
●
|
|
|
●
|
|
|
|
|
|
ARPEGE170-G-104
|
●
|
|
|
●
|
●
|
|
|
|
|
ARPEGE170-G-106
|
●
|
|
|
●
|
●
|
●
|
|
|
|
ARPEGE170-G-107
|
●
|
|
|
●
|
●
|
|
●
|
|
|
ARPEGE170-G-108
|
●
|
|
|
●
|
●
|
|
|
●
|
|
ARPEGE170-G-203
|
|
●
|
|
●
|
|
|
|
|
|
ARPEGE170-G-204
|
|
●
|
|
●
|
●
|
|
|
|
|
ARPEGE170-G-206
|
|
●
|
|
●
|
●
|
●
|
|
|
|
ARPEGE170-G-207
|
|
●
|
|
●
|
●
|
|
●
|
|
|
ARPEGE170-G-208
|
|
●
|
|
●
|
●
|
|
|
●
|
|
ARPEGE170-G-303
|
|
|
●
|
●
|
|
|
|
|
|
ARPEGE170-G-304
|
|
|
●
|
●
|
●
|
|
|
|
|
ARPEGE170-G-306
|
|
|
●
|
●
|
●
|
●
|
|
|
|
ARPEGE170-G-307
|
|
|
●
|
●
|
●
|
|
●
|
|
|
ARPEGE170-G-308
|
|
|
●
|
●
|
●
|
|
|
●
|
将您的ARPEGE70－110－140－170从液相转变到气相
如果您有一个ARPEGE的液氮罐，你可以通过替换部分电子器件及存储系统将其转变为气相液氮罐。我们为这种转变准备了特别的技术服务。
注意：为了安全起见，气相保存液氮罐必须配有一个自动填充系统。液氮罐和液氮源的连接是必要的。
